DTC Patchcord UTP CAT 5E

DTC Patchcord UTP CAT 5E

DESCRIPTION

DTC patch cable enable you to connect all hardware destinations on a local area network, Perfect for use with 10/100/1000 base - T networks and support Gigabyte Ethernet, they comes complete RJ45 male to male Connectors and snagless molded strain relief. Following Standard ISO/IEC 11801. EN 50173, EN 50168 dan EIA/TIA 568A/B, EIA/- TIA 568A-B.1-2, Connector Standard IEC 60603-7

  • 6-50 micron RJ-45 staggered gold plated connectors
  • Fitted with strain relief & transparent boots
  • With or without reports made to the order
  • 100% Tested Wiring Sequence and Continuity
  • Excellent Attenuation and Crosstalk Characteristics
  • Connector with staggered pin configuration to limit crosstalk
  • Exceed Category 5e requirement ( 100 Mbps Application)
  • They are available in a variety of the lengths
  • Concentration point
  • Patchpanel
  • Equipment termination
    • Durability
    1000 pluging
    Contact
    phosphor bronze with 50u gold plating
    Outer diameter
    5.6 mm
    Bend radius
    22.4 mm
  • 24 AWG bare copper
  • PVC or LSZH jacket
  • PE material isulation
  • PC polycarbonate material
  • 4 twisted pair, cross filler
  • CM/CMX flame test
